Pipe Fittings & Flanges Manufacturers

SS 317 Tubes Suppliers. Top Quality UNS S31700/1.4449 Seamless & Welded Tubes

Stainless Steel Tubes Tubing Manufacturers, Suppliers, Exporters
317 Stainless Steel Tubes Dealers in Mumbai

UNS S31700/1.4449, 317 Stainless Steel Tubes

₹305.00

SS 317 Seamless & Welded Tubes Manufacturers & Suppliers, UNS S31700/1.4449 Tubes

  • Equivalents: WRN. 1.4449, UNS S31700 , AISI 317
  • Specification: ASTM A312, ASTM A213, ASTM A268, ASTM A269
  • Size: 6mm to 101.4 mm, Thickness: 0.5mm to 10mm
  • Products: Seamless Tubes, Welded Tubes, ERW Tubes, Electropolished Tubes, Square Tubes, Rectangular Tubes, Thick Wall Tubes, Thin Wall Tubes, Decorative Tubes, Polished Tubes, Round Tubes
  • Stainless Steel 317 Tubes are available in sizes ranging from 1/4 in. OD to 5″ OD in. & lengths of 20 ft.

Metline is a professional stainless steel 317 tube supplier and manufacturer with more than 30 years experience. Our stainless steel 317 tubes are produced in compliance with ASTM A213/A269/A268 standards. SS 317 tubes supplied by Metline have excellent OD tolerance and mechanical properties enabling us to full fill the most demanding requirements from our customers. The quality of our tubes is ensured by our strict manufacturing process and testings at various stages of production.

Specifications:

  • ASTM A 269 Standard for Seamless Welded Stainless Steel Tube – Standard Specification for Seamless and Welded Austenitic Stainless Steel Tubing for General Service
  • ASTM A312 – Standard Specification for Seamless, Welded, and Heavily Cold Worked Austenitic Stainless Steel Pipes
  • ASTM A268 – Standard Specification for Seamless and Welded Ferritic and Martensitic Stainless Steel Tubing for General Service
  • ASTM A213 – Standard Specification for Seamless Ferritic and Austenitic Alloy-Steel Boiler, Superheater, and Heat-Exchanger Tubes

SS 317 Seamless Tubes, SS 317 Welded Tubes, SS 317 Tubes Manufacturers, SS 317 Welded Tubes Wholesalers, SS 317 Seamless Tubes Suppliers in Mumbai, SS 317 Seamless Tubes Importers

Categories: , Tags: , , ,

Description

Manufacturers & Suppliers of Stainless Steel 317 Tubes, UNS S31700/1.4449 Seamless & Welded Tubes

Metline is a specialist manufacturer and supplier of 317 stainless steel tubes with Bright Annealing (BA Tube) or Polishing (Surface Roughness Ra 0.18). We produce 317 stainless steel tubes outside diameter 6mm upto 5″, in wall thickness upto 10mm. Metline is a professional producer of both thin wall and thick wall stainless steel tubes, with exports to over 70 countries across the globe. In addition to 317 stainless steel tubes, we can also produce and supply related tube fittings such as ferrule fittings, compression fittings, and couplings and valves.

Pipes are used to transport something, and tubes to construct something; hence, tubes are defined by the outside diameter and wall thickness (for construction stability), and pipes are measured by inside diameter to allow a calculation for transportation viz., speed, volumes, etc.

Stainless Steel 317 Tubes Size and Weight Chart

Stainless Steel Tube Size and Weight
Wall Thickness in mm0.50.60.70.811.21.622.633.23.6
O. D. in mm Weight in kg/m
60.0690.0810.0930.1040.1250.1440.176–––––
100.1190.1410.1630.1840.2250.2640.336–––––
12.70.1530.1820.210.2380.2930.3450.444–––––
140.1690.2010.2330.2640.3250.3840.496–––––
15.870.1920.2290.2660.3010.3720.440.5710.694––––
190.2310.2760.320.3640.450.5340.6960.851.0661.21.264–
250.3060.3660.4250.4840.60.7140.9361.151.4561.651.7441.926
25.40.3110.3720.4320.4920.610.7260.9521.171.4821.681.7761.962
31.8–––––0.9181.2081.491.8982.162.2882.538
38–––––1.1041.4561.82.3012.6252.7843.096
44.5–––––1.2991.7162.1252.7243.1133.3043.681
50.8––––––1.9682.443.1333.5853.8084.248
63.5––––––2.4763.0753.9594.5384.8245.391
76.1––––––2.983.7054.7785.4835.8326.525
101.6––––––44.986.4357.3957.8728.82
114.3––––––4.4535.5477.1738.2478.789.84
127––––––4.9556.1757.9899.1889.78510.98
152.4––––––5.967.4299.6211.0711.79213.231

Production & Stock Range for 317, UNS S31700/1.4449 Stainless Steel Seamless & Welded Tubes

ProductStainless Steel 317 Tube
OriginIndia, Japan, Europe, US
FormWelded and Seamless
SpecificationASTM A213, ASTM A268, ASTM A269, ASTM A789, ASTM A790
TypeFluid, Food, Decorative, Structural, Instrumentation
Round Tube (mm)4.76 OD to 203.2 OD
Square (mm)12.7 to 152.6
Rectangular (mm)25.4 x 12.7 to 203.2 x 101.6
Grades
  • Austenitic Stainless Steel: 304/304L/304H(1.4301/1.4306/1.4948); 316/316L(1.4401/1.4404); 316Ti(1.4571); 321(1.4541); 309S (1.4833); 310S(1.4845); 317L(1.4438)321H(1.4878); 347H (1.4550);
  • Duplex Stainless Steel: S32001, S32003, S31500, 2205(1.4462); S32304,(1.4362);S31803,2507 (S32750), S32760(1.4501);S32101(1.4162);
  • Super Austenitic Stainless Steel: 904L, S30432, S31042, 6Mo (S31254, N08367)
  • Nickel Base Alloys: Alloy 20 (UNS N08020), Monel 200 (UNS 02200), Monel 400 (UNS N04400), Incoloy 800 (UNS N08800), Incoloy 800H (UNS N08810), Incoloy 800HT (UNS N08811), Incoloy 825 (UNS N08825), Inconel 600 (UNS N06600), 4J29, 4J36, GH3030, GH3039, C276 (UNS N10276)
  • Martensitic Stainless Steel: 410(1.4006), 410S(1.4000), 420(1.4021)
  • Ferritic Stainless Steel: 405(1.4002), 430(1.4016)
Wall Thickness0.33 to 10.0mm
FittingsTtri-clamp, Butt Welding, Flanges, Compression Fittings, Double Compression, Ferrule Fittings
ProcessingCut-to-length, Polishing, Bright Annealed, 180 Grit, 240 Grit, 400 Grit
Test CertificatesAs per EN 10204 3.1
Other TestsAs per Customer QAP, Hydro Test, Destructive & Non Destructive Tests
PackingBundled Packing, or Wooden Box Packing

About 317 Stainless Steel Tubes

317 was designed to be a higher strength alternative to the 316 grades. Composed of larger amounts of chromium, nickel and molybdenum, SS 317 also is more corrosion resistant compared to 316, and tougher than Type 304. This is the due to the high percentage of iron in its composition, which is much higher than many stainless steels. This combination of iron with the chromium-nickel-molybdenum content yields a strong, hardy alloy.

In terms of working capability, all common welding, hot working and cold working practices can be applied. 317 demonstrates good versatility. It will only work harden under cold working, which will also increase its strength. When heat treating this metal, temperatures should not drop below 1700°F as this is the threshold for response.

Stainless steel 317 is commonly found in the textile industry, where its strength and corrosion resistance can be utilized. Other applications include the manufacturing of chemical equipment and the machines used in pulping paper.

Types of 317, UNSS31700, 1.4449 Stainless Steel Seamless & Welded Tubes

SS 317 Seamless TubesUNS S31700 Seamless TubesWNR. 1.4449 Seamless Tubes
SS 317 Welded TubesStainless Steel 317 Round TubesStainless Steel 317 Square Tubes
Stainless Steel 317 Rectangular TubesFabricated 317 Stainless Steel Tubes317 Electropolished Tubes

Equivalents of 317, S31700/1.4449 Stainless Steel Seamless & Welded Tubes Grade

STANDARDWERKSTOFF NR.UNSJISBSGOSTAFNOREN
SS 3171.4449S31700SUS 317––––

Chemical Composition of  317, S31700/1.4449 Stainless Steel Seamless & Welded Tubes

GradeCMnSiPSCrMoNiN
317min.–––––183.0-4.011–
max.0.08210.040.032014–

Mechanical Properties of  317, S31700/1.4449 Stainless Steel Seamless & Welded Tubes

GradeTensile Strength (MPa) minYield Strength 0.2% Proof (MPa) minElongation (% in 50mm) minHardness
Rockwell B (HR B) maxBrinell (HB) max
3175152053575205

Physical Properties of 317, S31700/1.4449 Stainless Steel Seamless & Welded Tubes

GradeDensity (kg/m3)Elastic Modulus (GPa)Mean Coefficient of Thermal Expansion (m/m/0C)Thermal Conductivity (W/m.K)Specific Heat 0-1000C (J/kg.K)Electrical Resistivity (n.m)
0-1000C0-3150C0-5380Cat 1000Cat 5000C
317800019315.916.21714.218.7500740

Applications of UNS S31700, 1.4449, 317 Stainless Steel Seamless & Welded Tubes

  • Off-Shore Oil Drilling Companies
  • Power Generation
  • Petrochemicals
  • Gas Processing
  • Specialty Chemicals
  • Pharmaceuticals
  • Pharmaceutical Equipment
  • Chemical Equipment
  • Sea Water Equipment
  • Heat Exchangers
  • Condensers
  • Pulp and Paper Industry

Additional information

Product

Stainless Steel 317 Tubes, UNS S31700/1.4449 Stainless Steel Seamless & Welded Tubes

Product Size

OD (NB Sizes) 1/2" to 72"
Wall Thickness: SCH 5 to SCH XXS, Custom Thickness

Type

Seamless, Welded, Coiled, Straight Lengths

Material Grades

304, 304L, 316, 316L, 317/L, 321/321H, 310/310S, 347/347H, 904L, 254 SMO, Alloy 20, Duplex & Super Duplex

Quality Assurance

Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report

Marking

As per Manufacturing Specification, Heat Number Traceability

Export to Africa

Burundi, Comoros, Djibouti, Eritrea, Ethiopia, Kenya, Madagascar, Malawi, Mauritius, Mayotte, Mozambique, Reunion, Rwanda, Seychelles, Somalia, Tanzania, United Republic of Uganda, Zambia, Zimbabwe, Angola, Cameroon, Central African Republic, Chad, Congo (Brazzaville), Congo, Democratic Republic of the Equatorial Guinea, Gabon, Sao Tome and Principe, Algeria, Egypt, Libyan Arab Jamahiriya, Morroco, South Sudan, Sudan, Tunisia, Western Sahara, Botswana, Lesotho, Namibia, South Africa, Swaziland, Benin, Burkina Faso, Cape Verde, Cote d\\'Ivoire (Ivory Coast), Gambia, Ghana, Guinea, Guinea-Bissau, Liberia, Mali, Mauritania, Niger, Nigeria, Saint Helena, Senegal, Sierra Leone, Togo

Export to America

Anguilla, Antigua and Barbuda, Aruba, Bahamas, Barbados, Bonaire, Saint Eustatius and Saba, British Virgin Islands, Cayman Islands, Cuba, Curaçao, Dominica, Dominican Republic, Grenada, Guadeloupe, Haiti, Jamaica, Martinique, Monserrat, Puerto Rico, Saint-Barthélemy, St. Kitts and Nevis, Saint Lucia, Saint Martin, Saint Vincent and the Grenadines, Sint Maarten, Trinidad and Tobago, Turks and Caicos Islands, Virgin Islands (US), Belize, Costa Rica, El Salvador, Guatemala, Honduras, Mexico, Nicaragua, Panama, Argentina, Bolivia, Brazil, Chile, Colombia, Ecuador, Falkland Islands (Malvinas), French Guiana, Guyana, Paraguay, Peru, Suriname, Uruguay, Venezuela, Bermuda, Canada, Greenland, Saint Pierre and Miquelon, United States

Export to Asia

Afghanistan, Armenia, Azerbaijan, Bangladesh, Bhutan, Brunei Darussalam, Cambodia, China, Georgia, Hong Kong, India, Indonesia, Japan, Kazakhstan, South Korea, Kyrgyzstan, Laos, Macao, Malaysia, Maldives, Mongolia, Myanmar (ex-Burma), Nepal, Pakistan, Phillipines, Singapore, Sri Lanka (ex-Ceilan), Taiwan, Tajikistan, Thailand, Timor Leste (West), Turkmenistan, Uzbekistan, Vietnam

Export to Europe

Albania, Andorra, Belarus, Bosnia, Croatia, European Union, Faroe Islands, Gibraltar, Guerney and Alderney, Iceland, Jersey, Kosovo, Liechtenstein, Macedonia, Man, Island of Moldova, Monaco, Montenegro, Norway, Russia, San Marino, Serbia, Svalbard and Jan Mayen Islands, Switzerland, Turkey, Ukraine, Vatican City State (Holy See)

Export to European Union

Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, United Kingdom

Export to Middle East

Bahrain, Iraq, Iran, Israel, Jordan, Kuwait, Lebanon, Oman, Palestine, Qatar, Saudi Arabia, Syria, United Arab Emirates, Yemen
